Brand Name : BEFANBY
Model Number : KPT-0.5T
Certification : CE, SGS, ISO9001
Place of Origin : Henan,China
MOQ : 1 set/sets
Price : Negotiation
Payment Terms : L/C, T/T, Western Union
Supply Ability : 1500 set/sets per year
Delivery Time : 40-50 days as usual delivery,30-40days for urgent delivery
Packaging Details : Electrical parts will add shields. As required by the customer, we can add a fixed packing.
Power supply : Mobile cable
Running distance : According to customers' demand
Running speed : 0-20m/min
Color : Customized
Load capacity : 30 Tons
Warranty : 12 months
Product Name : roller table type scissor lift electric transfer cart
Application : metallurgy plant,Factory,coal plant
A rail electric transfer cart is an electric transport vehicle that runs on rails and is mainly used for in-factory cargo transportation. Its common names include electric transfer carts, rail transfer carts, electric flatbed cars, etc. Rail electric transfer carts usually require special tracks to be laid on the ground and are driven by electricity to move.
This model is the KPT series: a cable-powered electric transfer cart, suitable for places where production areas are relatively concentrated, such as small processing plants.
It can be used in a variety of transportation occasions, and also provides after-sales and customized services.
Model | KPT-2t | KPT-5t | KPT-10t | KPT-16t | KPT-20t | KPT-25t | KPT-30t | KPT-40t | KPT-50t | KPT-63t | KPT-80t | KPT-100t | KPT-150t | |
Rated Load | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
Table size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
Height(H) | 450 | 450 | 500 | 500 | 550 | 600 | 600 | 650 | 650 | 750 | 800 | 850 | 1200 | |
Wheel Base | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
Rail Inner Gauage | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
Wheel Diameter | 270 | 300 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
Motor Power | 0.8 | 1.5 | 1.5 | 2.2 | 2.5 | 3 | 4 | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | |
Max Wheel Load | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
Reference Weight | 2.3 | 3.3 | 3.8 | 5 | 5.5 | 6 | 6.3 | 7.2 | 7.6 | 10.3 | 12.1 | 13.9 | 26 | |
Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 |
