30t steel plant apply electric motorised transfer trolley on steel rail
This kind of steel motorised transfer trolley is running on steel rails or steel squre bars.It is commonly applied in steel plant, aluminum factory, plastic pipes factory, etc to transfer rounded material, from producing line to store. The power supply of the motorised transfer trolley can be customized, we can recommend client a suitable type according to their working site, It can be storage battery power, cable drum power, Busbar power, conductor rail power, towed cable power etc.
The 30t transfer trolley is cable drum powered, the cable drum is installed at the bottom of the rail cart.
Features of motorised transfer trolley
- Large load capacity is up to 300t;
- Has no limit on using time
- Has no limit on using frequency
- The V-shaped device, hydraulic lifting device can be added on the platform;
- With remote control, push button is available;
- Maximum safety to the operator;
- Has no strict requirement on rail installation
- Warranty period: one year;
Photo show of motorised transfer trolley
Application of motorised transfer trolley
Assembly line: Due to advantage of without cable, it is mainly applied in assembly line, can realize the straight rail, S shape rail, U shape rail, C shape rail, Arc-shaped rail, 90 degree turn rail, crossing rail etc.
Metallurgy industry: With the functions of steady traveling, stepless speed regulation, the cart is commonly applied to transfer steel ladle, aluminum ladle, lead ladle, steel slag etc. Generally the outer surface temperature of the ladle is 200-300 degree , due to the high temperature, the cart should be designed with heat exposure proof device, expecially to the battery, motor, reducer and electric appliance.
Ship industry: Due to the large load capacity, the cart is applied in ship industry to transfer workpieces, maintenance tools(propeller, motor etc.). The cart is also applied in dock or harbor to transfer cargoes and containers. If needed, the hydraulic lifting device , weighing device and automatic device can be added.
The motorised transfer trolleyis applied in metal industry factory to transfer large dimension steel plate, steel structure. The transport bogie is remote control, it is convenient to operate.
It is suitable to application with not so long running distance, high using frequency. It has no time limit.
The main parts of steel plant motorised transfer trolley is cart frame, motor, reducer, cable drum, electric appliance, etc.
These kind of motorised transfer trolley is applied to transfer heavy steel or aluminum coils. In order to inviod the steel coils falling down from the transfer cart, we designed a V-frame. It can protect the coils also the security. We can recommend you the direction of the V-frame according to the coils.
Generally the motorised transfer trolley is delivery through container. If the dimension of the transport is too large, it
can be break up or delivery through flat rack.
