Product Description Of Material Transfer Trackless Battery Cart

Trackless battery cart is a kind of material handling equipment that can drive directly on the ground, without laying track, so the movement of battery powered cart is more flexible, not only can drive straight, but also can turn and rotate.
The main components of trackless electric transfer cart include: frame, rubber wheels, electrical box, motor, reducer, brake, battery, charging machine, remote control, safety protection device. The advantages of rubber wheels are wear-resistant, not easy to cause damage to the ground, and flexible steering, which is also the reason why the electric flat cart can be formed between the hard ground. The trackless electric battery cart is installed with a DC motor. The advantages of DC motor are: DC motor maintenance costs are very low; The DC motor has excellent starting characteristics and speed control characteristics; Dc motor is more energy saving and environmental protection. We install a maintenance-free battery for the trackless transfer cart, the type of battery is selected according to the customer's working conditions. At the same time, for the convenience of charging, we are also equipped with a portable charger. The worker controls the movement of the electric flat cart through the remote control, and can operate the vertical and horizontal movement and rotation of the transfer cart. The electric trackless cart is also equipped with a laser sensor that immediately stops operation when it scans for obstacles, improving the safety of transportation.
Our electric transfer carts are sold all over the world, more than 90 countries. Our company has a professional design team and production team, electric flat cart production experience of more than 20 years. We will customize appropriate solutions according to customers' specific working conditions to meet customers' transportation needs.

Application Of Material Transfer Trackless Battery Cart

Product Details Of Material Transfer Trackless Battery Cart

Product Parameter Of Material Transfer Battery Cart

Model		BWP-2T	BWP-5T	BWP-10T	BWP-15T	BWP-20T	BWP-25T	BWP-30T	BWP-40T	BWP-50T	BWP-60T	BWP-70T	BWP-80T	BWP-100
Rated load(t)		2	5	10	15	20	25	30	40	50	60	70	80	100
Table Size	Length(L)	2000	2200	2300	2400	2400	3500	3500	5000	5500	5600	6000	6500	6600
	Width(W)	1500	2000	2000	2100	2200	2200	2200	2500	2600	2500	2600	2800	3000
	Heigth(H)	450	500	550	600	600	700	700	800	800	850	900	950	1200
Wheel Base(mm)		1080	1650	1650	1600	1650	1650	1650	2000	2000	1800	1850	1950	2000
Axle Base(mm)		1380	1680	1700	1830	1850	2700	2700	3600	2850	2900	3500	3500	4000
Wheel Dia.(mm)		Φ250	Φ300	Φ350	Φ400	Φ400	Φ450	Φ450	Φ500	Φ600	Φ600	Φ600	Φ600	Φ600
Wheel Quantity(pcs)		4	4	4	4	4	4	4	4	4	4	6	6	8
Ground Clearance(mm)		50	50	50	50	50	50	50	50	50	75	75	75	75
Running Speed(mm)		0-25	0-25	0-25	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-18
Motor Power(kw)		2*1.2	2*1.5	2*2.2	2*3.5	2*4.5	2*5.5	2*5.5	2*6.3	2*7.5	2*10	2*12	30	40
Batter Capacity(Ah)		250	180	250	330	400	400	450	440	500	600	600	800	1000
Battery Voltage(V)		24	48	48	48	48	48	48	72	72	72	72	72	72
Running Time When Full Load		2.5	2.88	2.8	2.3	2.2	1.8	2	2.6	2.5	2.2	1.8	2	1.9
Running Distance for One Charge(Km)		3	3.5	3.4	2.8	2.7	2.2	2.4	3.2	3	2.7	2.2	2.4	2.3
Max Wheel load(KN)		14.4	25.8	42.6	64.5	77.7	94.5	110.4	142.8	174	221.4	152	185	190
Reference Wight(t)		2.3	3.6	4.2	5.5	5.9	6.5	6.8	7.6	8	10.8	12.8	14.6	26.8
